Suppose you have a simple circuit whose wire changes in thickness. The wire is 8 meters long. The first 2 meters of the wire are 3 mm thick. The next 2 meters are 1 mm thick. The last 4 meters are 3 mm thick. The wire is connected to a 12-Volt battery and current is allowed to flow. You use an ammeter and a voltmeter to find that the current through the first 2 meters of wire is $I_1 = 5 \text{ A}$, and the voltage across the first two meters is $\Delta V_1 = 1 \text{ V}$. In all three segments of the wire, determine the magnitude of the electric field inside and the power transmitted.

• Segment lengths: $L_1=2 \text{ m}$, $L_2=2 \text{ m}$, and $L_3=4 \text{ m}$.
• Segment diameters: $d_1=3 \text{ mm}$, $d_2=1 \text{ mm}$, and $d_3=3 \text{ mm}$.
• Current: $I_1 = 5 \text{ A}$.
• Voltage: $\Delta V_1 = 1 \text{ V}$.

• Power and electric field in all segments

• The circuit is in a steady state.
• Approximating the battery as a mechanical battery.
• The wire has a circular cross-section.
• No outside influence on the circuit.
• The wire is made of the same material throughout.

• We represent the situation with diagram below. We number the segments for simplicity of representing the quantities we are interested in (see above in “Facts”).

Let's start with node $A$. Incoming current is $I_1$, and outgoing current is $I_2$. How do we decide if $I_{A\rightarrow B}$ is incoming or outgoing? We need to bring it back to the Node Rule: $I_{in}=I_{out}$. Since $I_1=8 \text{ A}$ and $I_2=3 \text{ A}$, we need $I_{A\rightarrow B}$ to be outgoing to balance. To satisfy the Node Rule, we set

$$I_{A\rightarrow B} = I_{out}-I_2 = I_{in}-I_2 = I_1-I_2 = 5 \text{ A}$$

We do a similar analysis for node $B$. Incoming current is $I_{A\rightarrow B}$, and outgoing current is $I_3$. Since $I_{A\rightarrow B}=5 \text{ A}$ and $I_3=4 \text{ A}$, we need $I_{B\rightarrow D}$ to be outgoing to balance. To satisfy the Node Rule, we set

$$I_{B\rightarrow D} = I_{out}-I_3 = I_{in}-I_3 = I_{A\rightarrow B}-I_3 = 1 \text{ A}$$

For node $C$, incoming current is $I_2$ and $I_3$. There is no outgoing current defined yet! $I_{C\rightarrow D}$ must be outgoing to balance. To satisfy the Node Rule, we set

$$I_{C\rightarrow D} = I_{out} = I_{in} = I_2+I_3 = 7 \text{ A}$$

Lastly, we look at node $D$. Incoming current is $I_{B\rightarrow D}$ and $I_{C\rightarrow D}$. Since there is no outgoing current defined yet, $I_{D\rightarrow battery}$ must be outgoing to balance. To satisfy the Node Rule, we set

$$I_{D\rightarrow battery} = I_{out} = I_{in} = I_{B\rightarrow D}+I_{B\rightarrow D} = 8 \text{ A}$$

Notice that $I_{D\rightarrow battery}=I_1$. This will always be the case for currents going in and out of the battery (approximating a few things that are usually safe to approximate, such as a steady current). In fact, we could have treated the battery as another node in this example. Notice also that if you incorrectly reason about the direction of a current (incoming or outgoing), the calculation will give a negative number for the current. The Node Rule is self-correcting. A final diagram with directions is shown below.
